Paddle court fencing

⚙️ 1. Product Definition and Core Functions

The board-type tennis court net is specifically designed for Padel. It is a fully enclosed protective system that combines a high-strength metal frame, tempered glass barriers, and customized netting structure. The core functions include:

Safety isolation: Preventing the ball from flying out of the playing area and causing injuries, protecting people and facilities outside the field 138.

Dynamic ball control: By taking advantage of the rebounding properties of the netting and glass walls, this technique helps maintain the pace of the game, reduces the time spent picking up the ball, and enhances the continuity of the movement. 67

Environmental Adaptability: Suitable for various indoor and outdoor surfaces (such as cement, artificial turf, asphalt), compatible with both temporary and permanent construction needs of the site 12.

??️ 2. Structural Design and Technical Highlights

1. Layered Composite Structure

Bottom tempered glass wall:

Use automotive-grade tempered glass (with a thickness of 3.0mm or more), which is shock-resistant and equipped with a break-proof design. The joint area is embedded with silicone pads to buffer and reduce vibration by 12.

The height of the end walls on the singles court is 3 meters, while on the doubles court it reaches 4 meters. The height of the side walls gradually changes (4 meters at the end → 3 meters in the middle), which complies with the international competition standard of 36.

Top metal fence net:

Mesh size: 50×50mm or 60×60mm. Wire diameter: 2.5 - 3.15mm. Galvanized or PVC coating (available in black, green, or orange). Corrosion-resistant and UV-resistant (458).

The frame is made of Ø114mm round or square tubes, with a wall thickness of ≥ 3.0mm. It is reinforced by polyester powder coating to enhance structural stability at 12.

2. Professional sports performance optimization

Ground system: Artificial short grass pavement, in line with the GB36246-2018 anti-slip and wear-resistant standards, ensuring the rebound height of the ball to be 135 - 145 cm (close to the performance of tennis balls) 16.

Lighting configuration: Integrated with 8 LED lighting units, providing uniform illumination without glare. Supports night events 12.

⚡️ 3. Core Advantages

Fast installation and flexible deployment:

Modular design, supporting delivery within 7 days, on-site assembly without the need for foundation construction; detachable and relocatable, suitable for renovation projects such as parking lots, rooftops, and squares 124.

Low cost, high return:

The area is only one quarter of that of a traditional tennis court, reducing the land and construction costs by over 30%; maintenance only requires rinsing and sweeping, and local damage can be repaired by replacing individual pieces 27.

Safety and Durability:

Passed the AS 1725.4-2010 wind load resistance certification, with a lifespan exceeding 10 years; The rounded corners and anti-climbing mesh design reduce the risk of sports injuries by 58%.

?? IV. Technical Specifications and Customization Services

Project Standard Specifications Customization Options

Court Size 20m × 10m (doubles) 13 Length and width can be adjusted as needed (e.g., singles 6 × 20m)

Net Height End walls 4m + Net 1m 3 分级定制 4 (1.2m - 3.0m)

Surface Treatment PVC Coating (Dark Green/Orange) 3 Enterprise LOGO， multi-color blending 8

Companion Components LED Lighting， Artificial Grass， Mobile Ball Rack Base 1 Pad cushioning layer， intelligent scoring system
